MK-6810V Polymethacrylate (PMA) Viscosity Index Inhibitor for Gear Oil
According to SAE J306, the 100℃ kinematic viscosity of gear oil should remain within the viscosity range after a 20-hour KRL shear test, for example, the 100℃ kinematic viscosity of grade 90 oil should be above 13.5 mm²/s after shear. At the same time, outstanding low-temperature fluidity is also needed to meet the low-temperature Brookfield viscosity requirements.
Polymethacrylate Viscosity Index Inhibitor Typical Data
|
Item
|
Typical Data
|
Test Method
|
|
|
MK-6810V
|
|||
|
Appearance
|
Transparent Viscous Liquid
|
Visual Check
|
|
|
Kinematic Viscosity(100℃), mm²/s
|
400-600
|
GB/T265
|
|
|
Colour, number
|
0.5
|
GB/T6540
|
|
|
Density (20℃), kg/m³
|
920
|
SH/T0604
|
|
|
Flash Point (Open Cup), ℃
|
160
|
GB/T3536
|
|
|
Thickening Ability
|
2.23
|
SH/T0622Appendix A
|
|
|
PSSI
|
Diesel InjectorShear, 30 Cycles, %
|
0
|
SH/T0103
|
|
Diesel InjectorShear, 90 Cycles, %
|
0
|
||
|
Diesel InjectorShear, 250 Cycles, %
|
0
|
||
|
KRL 20h, %
|
10
|
NB/SH/T0845
|
|
|
Note: According to Appendix A, the product is added to HVI150 base oil, and the increase in kinematic viscosity (100℃)of the blended oil with 10% PMA viscosity index improver is measured.
|
|||
Thickening, Viscosity Index and Pour Point in Different Base Oils
|
100N
|
32#
|
|||||
|
MK-6810V
|
MK-6810V
|
|||||
|
wt%
|
0
|
5
|
10
|
0
|
5
|
10
|
|
Kinematic Viscosity (100℃), mm²/s
|
4.27
|
4.98
|
5.9
|
5.67
|
6.61
|
8.09
|
|
Kinematic Viscosity (40℃), mm²/s
|
18.59
|
21.93
|
26.96
|
29.5
|
34.27
|
43.57
|
|
VI
|
140
|
162
|
173
|
136
|
152
|
161
|
|
Pour Point, ℃
|
-40
|
-55 unfrozen |
-51
|
-20
|
-41
|
-38
|
Advantages in Industrial Gear Oil Formulation
|
Thermal Efficiency
|
Bearing Protection
|
MicropittingProtection
|
Additive Compatibility
|
Total Cost
|
|
|
Mineral Gear Oil
|
Low
|
Medium
|
Medium
|
High
|
Low
|
|
PAO/mPAOGear Oil
|
High
|
High
|
Medium
|
Low
|
High
|
|
Gear Oil with TC-051V
|
High
|
High
|
High
|
High
|
Medium
|
Applications in Gear Oil |
|||
|
Products
|
PSSI (KRL 20h)
|
Product Features
|
Suggested Applications
|
|
MK-6810V
|
10
|
Ultra-high Shear Stability and Excellent Low-temperature Performance
|
High-performance oil meeting OEM specifications
|
|
MK-6820V
|
20
|
High Shear Stability; Outstanding Low-temperature Brookfield Viscosity
|
SAE 75W-90, 75W-85, 75W-80, etc.
|
|
MK-6830V
|
40
|
Excellent Thickening Performance; Good Low-temperature Brookfield Viscosity; Designed for Low-viscosity Oil with Low Dosage Levels
|
SAE 75W-80, etc.
|
|
MK-6840V
|
50
|
Good Low-temperature Brookfield Viscosity; Designed for Low-viscosity Oil with Low Dosage Levels
|
SAE 75W-80, etc.
|
Polymethacrylate Viscosity Index Inhibitor Suggested Use
Add 5.0%~35.0%wt to the specified base oils. Given the different types of base oils, thickening, viscosity index and pour point tests of the blended oil are required to determine the exact amount ofMK-6810V,MK-6820V functional polymer needed.
Polymethacrylate Viscosity Index Improvers Packaging
Can be packaged in 200 L steel drums with a net weight of 175 kg or IBC tanks with a net weight of 900 kg.
Product Features:
-
High viscosity index & good low-temperature performance
- Excellent shear stability & outstanding formulation flexibility
Performance Advantages of Finished Gear Oil:
- Excellent blending flexibility & outstanding performance at high and low temperatures lExcellent shear stability & oil temperature reduction due to low tractive effort
- Excellent compatibility with rubber & good solubility with other additives
- Excellent thermal stability and oxidation stability
