Polymethacrylate Viscosity Index Improvers for Automatic Transmission Fluid

MK-6302V Polymethacrylate (PMA) Viscosity Index Improvers for Automatic Transmission Fluid

To ensure the viscosity stability of automatic transmission fluid at different temperatures and under various shear conditions, viscosity index improvers for automatic transmission fluid are characterized by excellent low-temperature performance, outstanding performance in improving the viscosity index and satisfactory shear stability, enabling the development of fuel-efficient transmission fluid to meet the increasing environmental requirements.

Polymethacrylate(pma) Viscosity Index Improvers for Automatic Transmission Fluid typical Data

Item		Typical Data	Test Method
Appearance		Transparent Viscou Liquid	Visual Check
Kinematic Viscosity (100℃), mm²/s		1000-1300	GB/T 265
Colour, number		0.5	GB/T 6540
Density (20℃), kg/m³		900	SH/T 0604
Flash Point (Open Cup), ℃		160	GB/T 3536
Thickening Ability		4.75	SH/T 0622 Appendix A
PSSI	Diesel Injector Shear, 30 Cycles, %	1.68	SH/T 0103
	Diesel Injector Shear, 250 Cycles, %	3.16
	KRL 20 h, %	46	NB/SH/T 0845
Note: According to Appendix A, the product is added to HVI150 base oil, and the increase in kinematic viscosity (100℃) of the blended oil with 10% PMA viscosity index improver is measured.

Formula Example DCTF

Formula Example DCTF	Amount%wt	OEM Standard
MK-6302V	9.8
MK-6126P	0
60N	17
100N	69.2
Functional AdditivesMK-8017	4
Kinematic Viscosity (100℃), mm²/s	7.2	7.0 -7.5
Kinematic Viscosity (40℃), mm²/s	29.48
VI	223
BF, (-40℃), mPa·s	4582.77	Not Higher Than 15000
PSSI, KRL (20h)	5.95	>3.5
Pour Point, ℃	-47	Not More Than -40
Flash Point, ℃	185	>180

Applications in Automatic Transmission Fluid
Products	PSSI (KRL 20h)	Product Features	Suggested Applications
MK-6301V	65	Efficient Thickening; Excellent Low-temperature Performance	DEXRON^®-III MERCON^®, UTTO
MK-6302V	46	Excellent Thickening Performance; Outstanding Low-temperature Brookfield Viscosity; Good Shear Stability	ATF, CVTF, DCTF DEXRON^®-IIIH
MK-6303V	40	Good Shear Stability; Outstanding Low-temperature Brookfield Viscosity	ATF, CVTF, DCTF DEXRON^®-VI, MERCON^®V
MK-6304V	20	High Shear Stability; Good Low-temperature Performance	Transmission oil requiring high shear stability, gearbox oil for battery electric vehicles, etc.

Suggested Use

Add 2.0%~20%wt to the specified base oils. For different types of base oils, we need to conduct thickening, viscosity index, and pour point tests on the blended oil to determine the exact amount of MK-6302V functional polymer required.

Packaging

MK-6302V is a solution of modified polymethacrylate (PMA) in deeply refined mineral oil, which can be packaged in 200 L steel drums with a net weight of 170 kg or IBC tanks with a net weight of 900 kg.
