MK-6230V Modified Polymethacrylate (PMA) Viscosity Index Improver (Pour Point Depressant and Thickener)
As a Modified Polymethacrylate (PMA) Viscosity Index Improver(pour point depressant and thickener), MK-6230V can both improve the viscosity index and depress the pour point while providing exceptional thickening function. It is suggested to be used for the thickening and pour point depression of hydraulic transmission oils and shock absorber oils.
Typical Data of the Modified Polymethacrylate (PMA) Viscosity Index Improver
| Item | Typical Data | Test Method |
| Appearance | Transparent Viscous Liquid | Visual Check |
| Kinematic Viscosity (100℃), mm²/s | 3100-3300 | GB/T 265 |
| Color, number | 0.5 | GB/T 6540 |
| Density (20℃), kg/m³ | 900 | SH/T 0604 |
| Flash Point (Open Cup), ℃ | 160 | GB/T 3536 |
| PSSI，Diesel Injector Shear, 30 Cycles, % | 66 | SH/T 0103 |
| Thickening Ability | 17 | SH/T 0622 Appendix A |
| Note: The product is added to HVI150 base oil, and the increase in kinematic viscosity (100℃) of the blended oil with 10% PMA viscosity index improver is measured. | ||
Thickening, Viscosity Index and Pour Point in Base Oils with High Viscosity
| base oil itself | 1# | 2# | 3# | 4# | |
| Base Oil 68# | 100 | 99.5 | 99 | 98.5 | 98 |
| MK-6230V, wt% | 0 | 0.5 | 1.0 | 1.5 | 2.0 |
| Kinematic Viscosity (100℃), mm²/s | 8.51 | 9.97 | 10.72 | 11.71 | 12.74 |
| Kinematic Viscosity (40℃), mm²/s | 64.85 | 69.9 | 73.34 | 79.21 | 84.48 |
| VI | 101 | 126 | 134 | 141 | 149 |
| Pour Point, ℃ | -11 | -26 | -29 | -32 | -35 |
Thickening, Viscosity Index and Pour Point in Base Oils with Low and Medium Viscosity
| Base Oil | 100N | 250N | ||||||||
| MK-6230V，wt% | 0 | 0.5 | 1.0 | 1.5 | 2.0 | 0 | 0.5 | 1.0 | 1.5 | 2.0 |
| Kinematic Viscosity (100℃), mm²/s | 4.27 | 4.62 | 4.93 | 5.48 | 5.94 | 7.4 | 8.11 | 8.94 | 9.64 | 10.8 |
| Kinematic Viscosity (40℃), mm²/s | 18.59 | 19.77 | 21.13 | 23.18 | 24.94 | 50.23 | 53.58 | 59.16 | 62.69 | 68.27 |
| VI | 140 | 158 | 168 | 187 | 198 | 108 | 121 | 128 | 136 | 148 |
| Pour Point, ℃ | -40 | -55
UnfroZen |
-55
UnfroZen |
-55
UnfroZen |
-55
UnfroZen |
-22 | -38 | -40 | -40 | -42 |
Recommended Formula of MK-6230V in 6# Hydraulic Transmission Oil
| 6# Hydraulic Transmission Oil | Item | Test Result | |
| 4# Base Oil | 96.8% | Appearance | Transparent Oily Liquid |
| MK-6230V | 1.7% | Kinematic Viscosity (100℃), mm²/s | 5.88 |
| Functional Additives
MK-8036 |
1.5% | Kinematic Viscosity (40℃), mm²/s | 27.68 |
| Non-Silicon Defoamer | 300 ppm per ton | VI | 164 |
| Flash Point , ℃ | 191 | ||
| Pour Point, ℃ | -55 Unfro Zen | ||
Recommended Formula of MK-6230V in 15# Shock Absorber Oils
| Formula | ||
| 60N Base Oil | 95 | |
| MK-6230V | 3.5 | |
| Functional Additives
MK-8010 |
1.5 | |
| MK-PPD | 0 | |
| Non-Silicon Defoamer | 300ppm/Ton | |
| Item | Test Method | |
| Kinematic Viscosity (40℃), mm²/s | 15.49 | GB/T 265 |
| Kinematic Viscosity (100℃), mm²/s | 4.72 | GB/T 265 |
| VI | 247 | GB/T 1995 |
| Pour Point, ℃ | -50 | GB/T 3535 |
| Flash Point, ℃ | 164 | GB/T 3636 |
| Brookfield Viscosity (-40℃), mPa·s | 1292.37 | GB/T 11145 |
Suggested Use
Add 0.5%~8.0%wt to the specified base oils. Given the different types of base oils, thickening, viscosity index and pour point tests of the blended oil are required to determine the exact amount of MK-6230V functional polymer needed.
Packaging
MK-6230V is a solution of modified polymethacrylate (PMA) in deeply refined mineral oil, which can be packaged in 200 L steel drums with a net weight of 170 kg or IBC tanks with a net weight of 900 kg.
Product Features
- Exceptional thickening function
- Ability to depress the pour point
- Excellent performance in improving the viscosity index
- Outstanding filtering and anti-emulsifying performance
- The best thickener and pour point depressant for hydraulic transmission oils
